Measuring range includes Conductivity (0.00 to 20.00) μS/cm, (20.0 to 200.0) μS/cm, (200 to 2000) μS/cm, (2.00 to 20.00) mS/cm, (20.0 to 200.0) mS/cm, and (200 to 2000) mS/cm (K=10).
Innovative Technologies
- +44-111-222-3456
- info@quantixequipment.com
• 7-inch colored capacitive touch screen with high resolution (1024×600) and high sensitivity
• Built-in microprocessor chip has intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information
• Adopt advanced conductivity measurement technology, with conductivity electrode (K=1), it can meet measuring accuracy requirement for range of 0.5μS/cm ~ 200mS/cm
• Can switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity ensures conversion precision of the full scale
• Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China
• Supports PC connection
• Wireless Bluetooth printing and real-time data transfer to mobile phone are optional
• Smart electrode status display to ensure accurate use
• Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel
| Category | Specification |
|---|---|
| Conductivity Range |
Measuring range includes Conductivity (0.00 to 20.00) μS/cm, (20.0 to 200.0) μS/cm, (200 to 2000) μS/cm, (2.00 to 20.00) mS/cm, (20.0 to 200.0) mS/cm, and (200 to 2000) mS/cm (K=10). |
| TDS Range | (0 ~ 100) g/L |
| Salinity Range | (0 ~ 100) ppt |
| Resistivity Range | (0 ~ 100) MΩ·cm |
| Resolution | 0.01/0.1/1 μS/cm; 0.01/0.1/1 mS/cm |
| Accuracy | Electrode: ±0.5% FS; Meter: ±0.8% FS |
| Temp. Compensation | (0 ~ 50)℃, auto |
| Electrode Constant | 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100 cm⁻¹ |
| Reference Temperature | 25℃, 20℃, 18℃ |
| Temp. Range | (-10 ~ 110)℃ |
| Temp. Resolution | 0.1℃ |
| Temp. Accuracy | 5 ~ 60℃: ±0.4℃; Others: ±0.8℃ |
| Display | 7-inch colored capacitive touch screen |
| Data Storage | 1000 sets |
| Power | 12V / 1A |
| Output | USB |
| Ambient Temp. | 15 ~ 30℃ |
| Ambient Humidity | ≤85% |
| IP Grade | IP54 |
| Dimensions / N.W. | 215 × 170 × 37 mm / 600 g |
| Shipping Size / G.W. | 470 × 430 × 72 mm / 3 kg |
| Standard Accessories | Conductivity electrode (K=1), Temperature probe, Power adapter, Manual |
