● Beautiful appearance, small size and compact structure;
● Adopt high-performance silent axial fan, the machine running process is more silent;
● Wide gradient function of 30℃, can be used to optimize the experimental conditions to meet the demanding experimental needs.
● 5-inch high-definition color touch screen, intuitive and easy to operate, can easily edit, save and run the program;
● Industrial-grade operating system, can easily achieve 7×24 hours continuous error-free operation running;
● Fast data transfer to USB flash memory, easy to back up the programme and improve data storage capacity;
● Advanced semiconductor refrigeration technology and unique PID temperature control technology, so that the overall performance reaches a new height: high temperature control accuracy, fast temperature rise and fall rate, and good temperature uniformity of the module.
| Model | QXM-TC345 |
| Module Quantity | 1pcs |
| Semiconductor Quantity | 6pcs |
| Max Temperature Rise | 5℃/S |
| Max Temperature Fall | 4.5℃/S |
| Gradient Temperature Range | 30~105℃ |
| Gradient Setting Range | 0.1~42℃ |
| Temperature Uniformity | ≤±0.3℃ |
| Gradient Temperature Accuracy≤ | ±0.3℃ |
| Temperature Point Distributions | 12 |
| Thermal Cover Temperature Range | 30℃~110℃ |
| Intelligent Hot Lid Function | The thermal cap closes automatically when the sample temperature falls below 30°C or at the end of the programme. |
| Time Increase/decrease | -599s~599s |
| Temperature Increase/decrease | -9.9℃~9.9℃ |
| Power Supply | AC100~240V,50/60Hz |
| Temperature Control Method | Block/Tube |
| Module Temperature Range | 0~105℃ |
| Module Temperature Uniformity | ≤ ±0.25℃ |
| Module Temperature Accuracy | ≤±0.2℃ |
| Timing Range | 1s-59min59sec/0 is infinite |
| Adjustable Range of Temp | 0.1-5℃/S |
| Temperature Display Resolution | 0.1℃ |
| Sample Volume
|
96×0.2ml (semi-skirted, unskirted) 12×8 coupled tubes,
8×12 coupled tubes, single tubes (height 20~23mm) |
| Programme Storage | 10000+ |
| Max Number of Program Loops | 99 |
| Max Procedure Steps | 30 |
| Program Pause Function | Yes |
| Power Failure Recovery | Yes |
| 16℃Insulation Function | Infinite |
| Touchdown PCR Experiment | Yes |
| Long PCR Experiment | Yes |
| LCD | 5 inch |
| Operation system | Linux |
| Touch panel | Capacitance |
| Max power | 700W |
| Communication Interface | USB2.0 |
| External Dimension(mm) | 190x290x180 |
| NW(KG) | 4.5 |
