| Model | QXM-TS80 |
| Vessel Quantity | 18 |
| Vessel Volume | 100mL |
| Temperature Monitoring System | Temperature monitoring: Contactless IR sensor
Temperature control:Scanning control of each vessel Temperature control range: 50~400℃; Temperature control accuracy:±0.3℃ |
| Pressure Monitoring System | Contact-less pressure sensor
Pressure control range:0~10MPa Pressure control accuracy:0.01MPa |
| Vessel Material | Inner: imported TFM
Outer: imported PEEK+glass fiber |
| Display | 7-inch touch screen |
| Rotation Mode | 360° Continuous rotation |
| Microwave Power | 0-2000W adjustable/ 0-3000W adjustable |
| Microwave Leak | <5mW/cm² |
| Microwave Frequency | 2450MHz |
| Max. Working Pressure | 6MPa |
| Max. Working Temperature | 250℃ |
| Inner Vessel Temperature Limit | 300℃ |
| Electricity | AC 220V, 16A, 50/60Hz |
| Dimension(L*W*H) | 640*630*590mm |
| N.W./G.W. | 75kg/148kg(Main device+Accessories) |
| Shipping Dimension(L*W*H) | 800*800*810mm (Main device),620*590*560mm (Accessories) |
