Model | QTX-LC100 | QTX-LC200 | QTX-LC300 | QTX-LC400 | |
External Dimensions
(W*D*H)(mm) |
1050*710*1850 | 1320*710*1850 | 1625*710*1850 | 1930*710*1850 | |
Internal Dimensions
(W*D*H)(mm) |
950*615*625 | 1220*615*625 | 1525*615*625 | 1830*615*625 | |
Control System | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | ||||
Work Surface Height | 750mm | ||||
Airflow Velocity | Adjustable, 0.2~0.5 m/s | ||||
HEPA Filter | Efficiency | > 99.995% at particle size of 0.3 μm | |||
Dimensions(W*D*H)(mm) | 895*470*70 | 1190*470*70 | 1505*470*70 | 895*470*70 | |
Quantity | 1pc | 1pc | 1pc | 2pcs | |
Pre-Filter | Material | made of washable polyester fiber | |||
Dimensions(W*D*H)(mm) | 500*425*2 | 800*425*2 | 800*425*2 | 1000*425*2 | |
Quantity | 1pc | ||||
Sound Emission | ≤62dB(A) | ||||
Lighting Lamp | 6.5W*1 | 9.6W*1 | 9.6W*1 | 6.5W*2 | |
LED Type, Intensity ≥900Lx | |||||
UV Lamp | 20W*1 | 30W*1 | 30W*1 | 20W*2 | |
With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | |||||
Power Consumption | 155W | 285W | 285W | 300W | |
Doesn’t include external device connected via power socket | |||||
Cabinet Construction | Main Body: Electro-galvanized steel with antimicrobial Powder Coating | ||||
Work Zone: Stainless steel, grade 304 | |||||
Manual Sliding Sash: 5 mm UV Resistant Tempered Glass with counter-balance system and ergonomic handle | |||||
Side Windows: 5 mm UV Resistant tempered glass | |||||
Electricity | AC220V ±10%, 50/60Hz,1P | ||||
Standard Accessories | Base stand*1;
LED lamp*1(only 2 for LCB-V6F); UV lamp*1(only 2 for LCB-V6F); Waterproof socket*2; Foma casters*4 |
||||
Optional Accessories | Wind speed sensor; Gas tap;Water tap;Casters with brakes ;Hook and hook bar | ||||
Shipping Weight(kg) | 225 | 255 | 285 | 330 | |
Shipping Dimensions(W*D*H)(mm) | 1190*990*1340 | 1640*1000*1340 | 1770*990*1330 | 2070*990*1325 | |
Shipping Volume (m3) | 1.56 | 1.92 | 2.33 | 2.7 |
