● Stainless steel ceramic coated working plate surface is chemical resistant and pollution free;
● Wide range of temperature control up to 350°C;
● Mica sheet heating high temperature insulation corrosive thermal conductivity superior, more uniform heating;
● DC brushless motor, low noise, low maintenance, smooth operation and long service life;
● Heating function is controlled separately, and the button is highlighted when heating is on, which is convenient to operate;
● Aluminum die-casting ceramic coated working plate with superior resistance to abrasion, corrosion and high temperature oxidation;
● Dual heating control circuits, which can continue to maintain temperature stability when one heating circuit fails;
● The knob is equipped with operation locking and anti-misoperation function, which prevents accidental change of operation status and improves experimental safety;
● Pressed aluminum sealed thermal insulation shell effectively prevents liquid and gas from entering the interior of the instrument and protects circuit components
from corrosion.
| Model | QXM-MS246 |
|---|---|
| Max Capacity (H2O)L | 20 |
| Whole Machine power(W) | 600 |
| Motor output power(W) | 15 |
| Heating output power(w) | 550 |
| Rotational speed adjustable range(rpm) | 0–2000 |
| Heating plate size(mm) | 145 |
| Plate material | stainless steel ceramic coating |
| Heating method | mica sheet |
| Motor type | DC brushless motor |
| Display method | Graduated Scale |
| Motor display accuracy(rpm) | – |
| Temperature control range(℃) | RT+5~350 |
| Temperature resolution(℃) | – |
| Over temperature protection(℃) | ≤420 |
| Sensor temperature control accuracy(℃) | – |
| Temperature control accuracy(℃) | – |
| Temperature set accuracy(℃) | – |
| Timer Range | – |
| Stirrer length range (mm) | 20–80 |
| Power Supply(V/HZ) | 220 50/60 |
| Allowable ambient temperature/humidity | 5–40℃/80% |
| Instrument size (mm) | 165*280*105 |
| Packing size(mm) | 425*390*200 |
| NW(kg) | 4 |
| GW(kg) | 5 |
