| Model | QTX-BBS-C500 | QTX-BBS-C600 | QTX-BBS-C700 | QTX-BBS-C800 | ||
| External Dimension
(W*D*H)(mm) |
1100*780*2250 | 1300*780*2250 | 1500*780*2250 | 1800*780*2250 | ||
| Internal Dimension
(W*D*H)(mm) |
940*600*660 | 1150*600*660 | 1350*600*660 | 1625*600*660 | ||
| Tested Opening | Safety height 200mm | |||||
| Max. Opening | 480mm | |||||
| Inflow Air Velocity | 0.53±0.025m/s | |||||
| Down flow Air Velocity | 0.33±0.025m/s | |||||
| ULPA Filter | 2pcs,99.9995% efficiency at 0.12μm,filter life indicator | |||||
| Front Window | Motorized,6mm two-layer laminated toughened glass ,Anti UV | |||||
| Sound Emission | ≤65dB | |||||
| UV Lamp | 30W*1 | 30W*1 | 40W*1 | 40W*1 | ||
| LED Lamp | 12W*2 | 14W*2 | 16W*2 | 16W*2 | ||
| Illumination | ≥1000Lux | |||||
| Consumption | 1300W | 1300W | 1300W | 1300W | ||
| Waterproof Socket | total load of two sockets:500W | |||||
| Display | Color Touch Screen | |||||
| Control System | Microprocessor | |||||
| Airflow System | 100% air exhaust | |||||
| Visual and Audio Alarm | Abnormal airflow velocity, filter replacement,front window at unsafe height,
high filter pressure alarm, abnormal power failure |
|||||
| Material | Work Zone:304 stainless steel Main Body:Cold-rolled steel with anti-bacteria powder coating |
|||||
| Work Surface Height | 770mm (Can be customized) | |||||
| Caster | Footmaster caster | |||||
| Power Supply | AC 220V 50/60Hz; 110V/60Hz | |||||
| Standard Accessories | LED lamp*2pcs, UV lamp*2pcs, Base stand*1pc, Foot switch*1pc,
Drain valve*1pc, Water-proof socket*2pcs, Exhaust duct-4meters*1pc |
|||||
| Optional Accessories | Water and gas tap | |||||
| N.W/G.W(kg) | 225/373 | 260/425 | 280/455 | 340/525 | ||
| Package Dimension (W*D*H) (mm) | 1250*1080*1870 (Host);
930*800*700 (Fan) |
1450*1080*1870 (Host);
930*860*740 (Fan) |
1650*1080*1870(Host);
930*860*740 (Fan) |
1950*1080*1870 (Host);930*860*740 (Fan) | ||
