1.7-inch color LCD touch screen, graphical operation interface, Chinese and English display and print switching, keyboard input control, built-in clock and parameters can be set and have automatic storage function;
2.With positive sequence (descending sequence) sealing counter; It can realize the statistics of sealing quantity within 0 ~ 9999; It has special functions such as printing margins, printing interval symbols and so on.
3.With rapid heating and auxiliary cooling design: It equipped with a microcomputer-controlled heating and cooling mechanism to reduce the waiting time for the sealing temperature to quickly change from low to high or from high to low; It is efficient and energy-saving, and meets the working needs of fast-paced temperature conversion;
4.Computer intelligent temperature control design; working temperature: 60~220℃ arbitrarily set; temperature control accuracy is less than ±1%; Preset four common temperatures: 60℃, 120℃, 180℃, 220℃; It can realize fast switching according to the daily needs of users, which is convenient for users to quickly select the sealing temperature;
5.When the sealing temperature exceeds the working temperature setting range of ±4℃, the machine will automatically stop working, effectively ensuring the quality of the sealing and the safe operation of the equipment;
6.Floating constant pressure pressing structure design is adopted to meet the sealing needs of three-dimensional bags and paper bags of different thicknesses;
7.The standby time and standby temperature are adjustable, and the intelligent standby recovery function can make the machine return to the working temperature at a high speed, reducing the waiting time;
8.Advanced flat-plate ceramic heating components have the characteristics of fast temperature rise, uniform heating, high temperature resistance, long life and high thermal efficiency;
9.The equipment has its own operation identification function, which can realize the printing of test time, sealing temperature, pressure, speed, sealing time, equipment number, etc. in Chinese and English;
10.Optional stainless steel special sealing machine workstation with paper cutter, roller conveying platform and other peripheral configurations.
Sealing speed | 10±0.5 m/min |
Sealing margin | 0~35 mm adjustable |
Working temperature | 60~220℃ adjustable |
Temperature control accuracy | ≤ ±1% |
AC power supply | 220V±10% 50Hz |
Sealing pattern width | 12 mm |
Maximum current | 3.2A |
Fuse | 5A×2 |
Work rate | 500 W |
Dimensions(W*D*H) (mm) | 560×260×220 |
Package Dimension (W*D*H) (mm) | 700*400*350 |
G.W.(kg) | 18 |
