1. Built-in mouse control for autofocus and image measurement operations.

The significant innovation of QXM-AUT199 is making the software implant inside the camera. This feature liberates users from computers and annoying buttons. You can control the camera by only a mouse.

2. An unprecedented high-speed focusing experience.

QXM-AUT199 offers both continuous and single-shot autofocus modes. It also supports mouse wheel control for fine-tuning. Data transfer up to 60 frames per second enables users to get clear images with ease.

3. Record image and video to SD card.

Capture images at 6.0MP resolution (3264 × 1836), record high definition videos at 30fps/1080P into the inserted SD card directly.

4. High frame rate upto 60fps.

With 60fps preview frame rate at resolution 1920×1080 when it is connected via HDMI interface.

5. HDMI Fluorescent imaging Capability.

Taking advantage of the ultra high signal-to-noise ratio sensor, QXM-AUT199 allows you to set up to 10 seconds exposure time. So it can be used with fluorescent microscopes.

6. The functions inside camera (Cloud 1.0)

• Simple to operate.
• The implanted software is very simple to operate. There are only the icons on the software starting screen, one for capture, the other one for setting menu.
• Set Exposure Time Capability.
• Based on the auto exposure, the first time, HDMI camera also has a full control of the exposure time and gain. It allows to set the exposure time from 1ms to up to 10 seconds and adjusts 20 scales of Gain value.
• 3D Noise Reduction.
• The extension of the exposure increases the image noise. But the integrated 3D noise reduction function keeps the QXM-AUT199 image always clean and sharp. The following comparison images show the amazing 3D noise reduction effect.
• 1080P Video Recording.
• Just click “” to start recording 1080P videos at 30fps. The recorded video files will be saved to the high speed SD card directly. It is also allowed to play back the videos in the SD card directly.
• Get more Details with ROI Magnification Function.
• A series image operation buttons on the right side of the screen allow to do the image flip, rotation and zoom. Zoom function can help you get more image details with a magnified image.
• Image Comparison Function.
• The image comparison function is available in the setting menu. You can choose one image, even move the image position or select the ROI area to compare with the live images.
•  Browse Captured Images.
• All the captured images are saved in the SD card. The users can browse all the images in the SD card, zoom in images or delete unnecessary images. You also can review and play back the video files in the SD card directly.
• Measurement function when it is connected to LCD monitor.
• When it is connected to LCD monitor, QXM-AUT199 provides extremely powerful measurement functions including freehand line, rectangle, polygon, circle, bicircle, angle, point-line distance and much more. Three different length units of micrometer, millimeter and centimeter are provided to meet various measurement  requirements in different applications.

7. PC software.

Connect the camera to the PC via the USB2.0 port, the camera support Win XP, Win7/8/10, 32/64bit, MAC OSX operation system, driver free. The frame rate is 30fps(with 1080P resolution) when it is connected to PC. The application software Capture2.0, which integrate the remarkable functions like live and still image measurement, live EDF, live stitching, captured image stacking and stitching etc., can fully control the camera. We keep a copy of Capture2.0 in the SD card come with the camera.
